Portable screw air compressor with diesel driven LGCY-5

1, Portable screw diesel air compressor with wheels, which is single stage. Mobile diesel driven screw air compressor for drill rig, Rock Drill Marine Air Compressors.
2, Combining with the characteristics of domestic micro-piston air compressor, make full use of its strong technical advantages, and launch a micro-screw air compressor with environmental protection, energy saving and high reliability, which is more humanized and provides you great convenience for use.
3, Advanced design concepts.
4, The newly designed energy-saving screw assembly performs well in the industry.
5, Low noise makes the working environment quieter.
6, environmental design, low fuel consumption.
7, Easy to maintain compact structure, beautiful appearance, long maintenance interval and low cost.


About Our Portable Screw Air Compressor, LGCY Series Portable Screw Air Compressor are designed for a variety of segments like abrasive sandblasting, construction and mining. where they are used to drive heavy pneumatic tools like jack hammer, pavement breaker, chipping hammer, pneumatic pumps, down-The-Hole drills, drilling rigs, water well drilling, sand blasting etc.
1, Greater fuel efficiency and energy saving.
2, Air filtration system with vacuum indication for dust environments.
3, Compressor oil and engine coolant coolers to optimize performance and extend engine life.
4, Efficient compressor oil filter.
5, Fuel filter with water separator.
6, Easy to remove, translucent PE fuel tank.


Technical parameters
Model Working Pressure
(mpa)		 Air Capacity
(m3/min)		 Engine Power(HP) Air Outlet
Connector		 Weight(kg) Dimension(LxWxH mm)
LGCY-5/8(double tank) 0.8 5.0 xichai 50 HP G1x1, G1/2x1 740 1660x1020x1610
LGCY-5/7 0.7 5.0 Yuchai 50 HP G1 1/4x1, G3/4x1 1300 3240x1760x1850
LGCY-5/7R 0.7 5.0 Kubota 60 HP G1 1/4x1, G3/4x1 1300 3240x1760x1850
LGCY-6/7X 0.7 6.0 Xichai 75 HP G1 1/4x1, G3/4x1 1400 3240x1760x1850
LGCY-9/7 0.7 9.0 Yuchai 120 HP G1 1/4x1, G3/4x1 1550 2175x1760x1785
LGCY-12/10 1.0 12.0 Yuchai 160 HP G1 1/4x1, G3/4x1 1880 3300x1880x2100
LGCY-12/10K (China II) 1.0 12.0 Cummins 180 HP (China II) G1 1/4x1, G3/4x1 2050 3300x1700x1900
LGCY-12.5/14L (two wheels) 1.4 12.5 Cummins 180 HP G2x1, G3/4x1 2100 3520x1980x2256
LGCY-14/14L (two wheels) 1.4 14.0 Cummins 210 HP G2x1, G3/4x1 2400 3520x1980x2356
LGCY-27/10 1.0 27.0 Yuchai 340 HP G2x1, G3/4x1 5000 4600x1950x2850
LGCY-27/10K 1.0 27.0 Cummins 360 HP G2x1, G3/4x1 5000 4600x1950x2850
LGCY-32/10 1.0 32.0 Yuchai 400 HP G2x1, G3/4x1 5000 4600x1950x2850
LGCY-32/10K 1.0 32.0 Cummins 360 HP G2x1, G3/4x1 5000 4600x1950x2850
LGCG-65/5 0.5 65 Yuchai 560 HP DN125 8500 4500x2350x2380
