portable screw air compressor LGCY-11 for mining

1, LG series, SKY patented screw host Patented rotor profile, high efficiency, heavy-duty design, SKY bearing, direct drive, energy-saving principle, innovative design.
2, Dedicated engine with strong power equipped with heavy-duty specialized diesel engines such as Yuchai and Cummins, achieving the good combustion state throughout the entire range of engine operation, the product has higher reliability, stronger power, and better fuel economy.
3, Multi air filtration system:Effectively preventing the impact of harsh dust environments on engines The precision filter layer of the main air filter removes residual dust, ensuring that the machine The device is not worn out; The safety filter can allow the machine to operate without stopping the machine Filter maintenance to ensure safe operation of the machine.
4, Efficient cooling system: The design of independent oil, water, and air coolers combined with large-diameter fans adapts to harsh cold and hot climates.

Descriptions
Technical Parameters

5, Triple oil and gas separation system: Reduce the impact of excessive or insufficient oil injection into the separator on the oil content of compressed air, and always maintain the oil content of compressed air below 3ppm. Clean compressed air is beneficial for the safe operation of the equipment.
6, Low temperature starting system (optional): The water pump of the fuel heater draws the coolant from the engine body to the heat exchanger, and the oil pump draws the fuel from the mailbox to the burner and burns it. Through the continuous circulation of heat, the temperature of the coolant and the lubricating oil of the whole machine continuously increases, ensuring the starting performance of the diesel engine in harsh cold and high-altitude environments.
7, Remote start stop, monitoring, and positioning system (optional)

Please visit this page to read the Operating instructions Page First

Please visit this page to read the Operating instructions Page Second

Technical parameters
Model	Working Pressure (mpa)	Air Capacity (m3/min)	Engine Power(HP)	Air Outlet Connector	Weight(kg)	Dimension(LxWxH mm)
LGCY-11/18T (two wheels)	1.8	11	Yuchai 160 HP (4 cylinder)	G1 1/2x1, G3/4x1	2100	3400x2000x1930
LGCY-15/18-17/12T	1.8 to 1.2	15 to 17	Yuchai 190 HP (6 cylinder)	G2x1, G3/4x1	2200	3000x1520x2300
LGCY-17/18-18/15T	1.8 to 1.5	17 to 18	Yuchai 220 HP	G2x1, G3/4x1	2500	3000x1520x2300
LGCY-17/18-18/15TK	1.8 to 1.5	17-18	Cummins 210 HP	G2x1, G3/4x1	2500	3000x1520x2300
LGCY-19/21-21/18	2.1 to 1.8	19 to 21	Yuchai 260 HP	G2x1, G3/4x1	3600	3300x1700x2350
LGCY-19/21-21/18K	2.1 to 1.8	19 to 21	Cummins 260 HP	G2x1, G3/4x1	3600	3300x1700x2420
LGCY-21/21-23/18	2.1 to 1.8	21 to 23	Yuchai 310 HP	G2x1, G3/4x1	3900	3300x1800x2300
LGCY-23/23-25/18	2.3 to 1.8	23 to 25	Yuchai 340 HP	G2x1, G3/4x1	4500	4080x1950x2687
LGCY-23/23-25/18K	2.3 to 1.8	23 to 25	Cummins 360 HP	G2x1, G3/4x1	4850	4150x1950x2850
LGCY-27/25-29/18	2.5 to 1.8	27 to 29	Yuchai 400 HP	G2x1, G3/4x1	4500	4080x1950x2687
LGCY-25/23-27/18K	2.3 to 1.8	25 to 27	Cummins 360 HP	G2x1, G3/4x1	4850	4150x1950x2850
LGCY-26/25K	2.5	33	Cummins 550 HP	G2x1, G3/4x1	6800	4700x2160x2650
LGCY-26/25	2.5	26	Cummins QSZ13-C550-30	G2x1, G3/4x1	6800	4700x2160x2650
LGCY-33/25	2.5	33	Yuchai 560 HP	G2x1, G3/4x1	6800	4700x2160x2650
LGCY-33/25K	2.5	33	Cummins 550 HP	G2x1, G3/4x1	6800	4700x2160x2650
LGCY-39/25	2.5	39	Chongqing Cummins 700 HP	G2x1, G3/4x1	7200	4850x2160x2661
LGCY-39/25A	2.5	39	Catepillar 700	G2x2	7200	5000x2200x2850
LGCY-33/35	3.5	33	Chongqing Cummins 700 HP	G2x1, G3/4x1	7200	4850x2160x2661
LGCY-33/35A	3.5	33	Catepillar C18-650 HP	G2x2	7200	5000x2200x2850
LGCY-43/25-37/35Y	2.5 to 3.5	37 to 43	Volvo 760 HP	G2x1, G3/4x1	9000	5207x2200x2720
LGCY-30/8TK	0.8	30	Cummins 260 HP	G2 1/2x1, G3/4x1	3200	3600x1800x2480
LGCY-25/10TK	1	25	Cummins 260 HP	G2 1/2x1, G3/4x1	3200	3600x1800x2480
LGCY-21/13TK	1.3	21	Cummins 260 HP	G2 1/2x1, G3/4x1	3200	3600x1800x2480
